Additional information
| Weight | 35.28 kg |
|---|---|
| Dimensions | 33 × 17.3 × 25.1 cm |
| Case QTY | 1 |
| Cold Cranks | 1150 |
| Core | 30 |
| Cranking Amps | N/A |
| Polarity | '+ – |
| Terminal | SAE and 3/8-16” Stud (Pos.), 5/16-18” Stud (Neg.) |
| Volt | 12 |
| Reserve Minutes | 220 |
| Pulse (5 second) Hot Cranking Amps (PHCA) | 2150 |
| HCA | 1545 |
| MCA | 1370 |
| 20Hr Nominal Capacity (Ah) | 103 |
| 10Hr Nominal Capacity (Ah) | 98 |
| Torque Spec in-lbs (Nm max) | 200 (22.6)/100 (11.3) studs only |
| Internal Resistance (mΩ) | 2.2 |
| Short Circuit (A) | 5000 |
| Operating Temperature Range | -40°F / -40°C to 176°F / +80°C |
| Optimum Storage Temperature | 68°F / +20°C |
